PIONEER

ARC Pioneer is a brand name of itself - our real pioneer and pathfinder. Worldwide well-known and distinctive Arctos system, characteristic for its high-balanced whitelight laserpower, great compactness & stability. As every ARCTOS system, it incorporates a smart architecture of optics and electronics. Powerful indoor & outdoor, it covers the non-plus-ultra needs of every laser professional.
Also available with Penthouse Series, custom-designed grating box for the ARC Series.

PIONEER 30W

Top selling lasersystem for laser professionals.

---

637nm ARC RED
639nm ARC RED
532nm GREEN
445 ARC BLUE

Signal Interface

Signal Input-/Output USB DMX

ILDA Standard D-Sub 25p optional optional

TECHNICAL DATA

Scanning System Standard Scanning System Optional Scanning Features Manual inverse function ARCTOS Mainboard Blue LC-Display Operational Temperature Air-cooled system

CT 6800 / 35 kpps@8° with 1M0 CT 6215 / 60 kpps@8° with 3M0 Cambridge Technology with Servoamp Internal scanner safety circuit High speed 60.000 pps max. speed depend. on angle x/y-axis; offset and size Processor controlled Digital test mode, digital colour adjustment/calibration For internal function control 8°C up to 30°C [optimal operation temperature: 25°C] Intelligent low noise thermal-management system Automatic cooling/heating for optimal laser parameters Cooling of heat-generating components and exceptional internal heat dissipation.

COMPACT AND SOLID HOUSING MADE BY ARCTOS

CNC-milled black anodized aluminium
Mechanical levitated design
Automatic cooling/heating for optimal laser parameters
Dust proof optical compartment
Maintenance free and long lifetime
Ultra rugged, compact and reliable housing design

SYSTEM FEATURES

+ Compact solid housing made by ARCTOS
+ Integrated scanner plug`n play concept
+ Best stability and lifetime
+ Designed for laserprofessionals!
+ Dynamic Zone Safety
+ Energy Saving
+ Super Silent
+ ESD Protected Stabilized Switching Power Supplies
+ Microprocessor controlled
+ ARC-Modular construction
+ YOKE designed against shear forces
+ DMX Ready
+ Ethernet Ready

LASER CONTROL & SAFETY



+  The new electric mainboard manufactured by ARCTOS allows many system features +  Control of all internal operating voltages via blue LC Display +  Reduced fan noise by analog fan-control +  Faster service access +  Gradual power supply start for all +  "Softstart" for avoiding power peaks during switch-ON +  DMX menu guidance (FB3-Series) +  Auto mode for laser head disconnection +  Sequential cooling/heating depending on temperature peaks +  Shortened safety shutter speed time ca: 17msec

ACCESSORIES & EXTRAS

The ARC DIODE Series is available with additional Grating Box Module - Penthouse Edition
ARC-Remote control unit incl. CDRH-standard & time delay max.cable length 60m
Interlock AMP safety-standard for illuminated "Emergency"
Integrated Pangolin Flashback
RGB potentiometers
Gratings (holographic mirrors)
Customized Climate box for outdoor installations
Customized Flightcases Made by Amptown
